Overview of this 2560 R3 Improved Version CH340G atmel mega 16u2 Board
The ATmel MCU ATMEGA16U2 MEGA 2560 R3 Improved Version CH340G Board is an advanced microcontroller solution designed for complex projects. This atmel mega 16u2 Board features a powerful ATmega16U2 MCU, offering enhanced performance and flexibility. With the CH340G USB-to-serial chip, it provides reliable and seamless communication. The atmel mega 16u2 MEGA 2560 R3 board is ideal for both beginners and experienced developers looking for robust functionality.
The atmel mega 16u2 MEGA 2560 R3 CH340G board comes with multiple digital and analog I/O pins, enhancing project versatility. It supports various shields and sensors, making it suitable for a wide range of applications. The improved version ensures stable power management, optimizing the board’s efficiency. The ATmel MCU ATMEGA16U2 MEGA 2560 R3 Improved Version CH340G Board is perfect for creating innovative Arduino-based projects.
Features
- Enhanced Microcontroller Performance: Equipped with the ATmega2560 MCU for powerful processing capabilities and efficient performance. Ideal for complex applications, ensuring faster execution of multiple tasks with ease.
- Improved USB Interface with CH340G Chip: The CH340G USB-to-Serial converter provides a reliable and stable USB connection. Ensures seamless communication between the board and your computer for smooth data transfer.
- Large Memory Capacity for Versatile Projects: Boasts 256KB of flash memory, 8KB SRAM, and 4KB EEPROM. Perfect for storing large programs and handling multiple variables during project execution.
- Multiple Digital and Analog I/O Pins: Features 54 digital I/O pins and 16 analog input pins for extensive connectivity. Enables interfacing with a wide range of sensors, modules, and external devices.
- Built-in Power Management and Protection: Offers flexible power options via USB or external power supply (7-12V). Integrated protection circuits safeguard against overcurrent, ensuring long-lasting board reliability.
Specification
| Specification | Details |
|---|---|
| Microcontroller | ATmega2560 |
| USB Interface Chip | CH340G (USB to Serial) |
| Operating Voltage | 5V |
| Input Voltage (Recommended) | 7-12V |
| Input Voltage (Limit) | 6-20V |
| Digital I/O Pins | 54 (of which 15 provide PWM output) |
| Analog Input Pins | 16 |
| Flash Memory | 256 KB (of which 8 KB is used by bootloader) |
| SRAM | 8 KB |
| EEPROM | 4 KB |
| Clock Speed | 16 MHz |
| Communication Protocols | UART, SPI, I2C |
| USB Connector Type | USB Type-B |
| Power Jack | DC Barrel Jack |
| LED Indicators | Power, TX, RX, L (onboard LED), Pin 13 LED |
| Dimensions | 101.52 mm x 53.3 mm |
| Weight | Approximately 37 grams |
| SKU | RW-003 |
