Description
Overview of this Addressable Flexible WS2812B 16×16 Led Matrix Panel
Introducing roboway WS2812B 16×16 LED matrix panel is a versatile, high quality lighting solution. This addressable flexible LED matrix panel offers customizable lighting effect with 256 individually controllable RGB LED. Perfect for dynamic displays, this 16×16 flexible LED matrix panel is ideal for DIY project and creative installations. It provide a wide range of vibrant colors, controlled through simple programming via popular microcontroller.
It is specially designed for flexibility, this WS2812B addressable LED panel can bend to fit various surface. Its compact size and high brightness make it perfect for intricate design and animation. This panel’s addressable nature allow for precise control of each pixel, creating stunning visual effect. Whether for artistic displays or function lighting, this flexible LED matrix panel delivers superior performance.
Features
- High-Resolution Display: This ws2812b 16×16 matrix panel offers a resolution of 256 individual RGB LEDs. It provides vibrant and detailed visual effects with a wide color spectrum.
- Individually Addressable LEDs: Each LED in this addressable flexible led matrix panel can be controlled independently. This feature allow for intricate animations and custom lighting effect.
- Flexible Design: This panel is flexible and can be bent or shaped to fit various surface. Its adaptability makes it suitable for curved or irregular installations.
- Easy Integration: It is also compatible with popular controller and microcontroller like Arduino and Raspberry Pi. Simple to integrate into existing projects or new designs.
- Low Power Consumption: This WS2812B 16×16 led matrix panel operate efficiently, consuming minimal power while delivering bright, colorful displays. Ideal for energy conscious applications without sacrificing performance.
Specification
| Specification | Details |
|---|---|
| LED Type | WS2812B SMD5050 RGB LED |
| Panel Size | 16×16 LEDs (256 total LEDs) |
| Pixel Pitch | 10mm |
| Panel Dimensions | 160mm x 160mm |
| Control Method | Single data line (DIN) for addressable control |
| Input Voltage | 5V DC |
| Power Consumption | Max 60W (at full brightness, all LEDs white) |
| Color Depth | 24-bit (16,777,216 colors per pixel) |
| Frame Refresh Rate | Up to 400Hz |
| Viewing Angle | 120 degrees |
| Operating Temperature | -25°C to +80°C |
| Waterproof Rating | IP20 (Non-waterproof) |
| Communication Protocol | Integrated driver chip, uses standard 3-pin JST-SM connector |
| SKU | RW-858 |
