Description
Overview of this 0-100V 10A Dual Voltmeter Ammeter Digital display
Introducing the 0-100V 10A dual Voltmeter ammeter Digital display, a versatile module for precise voltage and current measurement. This digital LED display module accurately monitors voltage and current simultaneously, with a range of 0-100V and 10A. Its dual-display design provides clear readings for both parameters, making it ideal for various electrical applications.
The 0-100V 10A Digital LED Voltmeter Ammeter ensures easy integration into your projects with its compact size and straightforward wiring. Whether you’re working on DIY electronics, automotive projects, or power supply monitoring, this module offers reliable performance and accuracy. Its LED displays provide clear visibility even in low-light conditions, ensuring effortless monitoring of your electrical systems.
Features
- LED Display: This 0-100V 10A dual Voltmeter ammeter Digital display built with LED displays for simultaneous voltage and current measurements, enhancing convenience and readability. This feature allows users to monitor both parameters at a glance, streamlining troubleshooting and analysis processes.
- Wide Measurement Range: Capable of measuring voltage from 0 to 100 volts and current up to 10 amps, catering to a variety of applications. This wide measurement range accommodates diverse voltage and current levels commonly encountered in electronic circuits and projects.
- High Accuracy: Offers high accuracy in voltage and current measurements, ensuring precise readings for better control and monitoring. This accuracy is crucial for maintaining the integrity and stability of electronic systems, particularly in critical applications.
- Compact and Easy to Install: Designed to be compact and easy to install, suitable for integration into various projects and setups. Its user-friendly design simplifies installation and setup processes, making it accessible to users with varying levels of expertise.
- Multiple Protection Features: This 0-100V 10A dual Voltmeter ammeter Digital display also features multiple protection such as reverse polarity protection and over current protection. And also provide safety for both the module and connected circuits.
Specification
| Specification | Description |
|---|---|
| Measurement Type | Voltage and Current |
| Measurement Range | Voltage: 0-100V, Current: 0-10A |
| Display | LED Display |
| Display Resolution | Voltage: 0.1V, Current: 0.01A |
| Accuracy | Voltage: ±1% + 2 digits, Current: ±2% + 5 digits |
| Operating Voltage | 4.5V – 30V |
| Operating Current | < 20mA |
| Refresh Rate | > 200ms |
| Operating Temperature | -10°C to +65°C |
| Dimensions (L x W x H) | 48mm x 29mm x 26mm |
| Weight | 20 grams |
| Input Impedance | Voltage: > 100kΩ, Current: < 50mΩ |
| Reverse Polarity Protection | Yes |
| Overcurrent Protection | Yes |
| Mounting Holes | Yes |
| SKU | RW-142 |
