PC817 4 channel Optocoupler Isolation Module

SKU: RW-493
Model PC817
Number of Channels 4
Isolation Voltage 5000 Vrms (minimum)
Input Forward Voltage 1.2V typical, 1.4V maximum
Input Forward Current 20 mA typical

115.00 ( Excluding 18% GST )

In stock

15 People watching this product now!
  • Get 10% off on order above 2000₹ use ROBOWAY10
  • Same day delivery in Delhi Ncr Region
  • Free delivery in all over India within 1-4 Days

Overview of this PC817 4 channel Optocoupler Isolation Module

Introducing roboway PC817 4 channel optocoupler isolation module at best price for electronic projects. This PC817 4 ch Optocoupler easily isolate and protect various parts of your circuit. It also ensures safe and efficient signal transmission between different voltage level. This module design enhance performance and reliability in your project.

This 4 channel Optocoupler Isolation Module PC817 is easy to use into any setup. Each of the four channels provide robust isolation & provide safety to sensitive component. This isolation module is important for application including microcontroller and high power device. It also help to prevent electric interference and damage.

With its 4 channel Optocoupler PC817 Isolation Module your projects achieve higher stability and safety. The PC817 optocouplers within the module ensure precise signal communication. It is ideal for industry control, automation, and DIY electronics projects.

Features

  • High Voltage Isolation: ThPC817 4 ch Optocoupler module offers high isolation between input and output circuits. This ensures safe communication between high and low voltage system.
  • Low Input Current Requirement: It also operates effectively with a low input current of around 5mA. This makes it energy efficient and best choice for low power device.
  • Wide Operating Voltage Range: The module support a wide operating voltage range from 3V to 30V. This flexibility allows it to be used in various electronic project.
  • Compact Design: The PC817 optocoupler module features a compact design for easy integration. It is ideal for space-constrained applications in both industrial and consumer electronics.
  • Reliable Signal Isolation: It provides reliable signal isolation to prevent electrical interference. This ensures accurate signal transmission and system stability.

Specification

Specification Description
Model PC817
Number of Channels 4
Isolation Voltage 5000 Vrms (minimum)
Input Forward Voltage 1.2V typical, 1.4V maximum
Input Forward Current 20 mA typical
Collector-Emitter Voltage 35V (maximum)
Collector Current 50 mA (maximum)
Current Transfer Ratio (CTR) 50% to 600% (depending on model)
Response Time Rise Time: 3 μs, Fall Time: 2 μs (typical)
Operating Temperature Range -30°C to +100°C
Package Type DIP-16 (4 optocouplers in one package)
Input Type DC input
Output Type NPN transistor output
Insulation Resistance ≥5×10^10 Ω (500 V DC)
Storage Temperature Range -55°C to +125°C
SKU RW-493
