Overview of this TPA3116D2 XH-M543 120W Dual Channel Amplifier
Introducing Roboway TPA3116D2 XH-M543 120W Dual Channel Amplifier delivers exceptional audio performance for any audio setup. This powerful amplifier board provides up to 120W output, ensuring high-quality sound reproduction. Designed with efficiency in mind, the XH-M543 120W Digital Dual Channel Amplifier utilizes advanced circuitry for minimal distortion. Ideal for home theater systems or DIY projects, this amplifier board enhances your listening experience.
Compact and easy to integrate, the XH-M543 Digital Power Amplifier Board is perfect for various applications. Featuring robust thermal management, the TPA3116D2 XH-M543 Amplifier Board ensures reliable operation during extended use. Its dual-channel configuration allows seamless connectivity with multiple speakers for a surround sound experience. Upgrade your audio system with the outstanding performance of this digital amplifier board.
Features
- High Power Output: Delivers up to 120W per channel at a 4-ohm load. This capability makes it suitable for driving larger speakers in various audio applications.
- Digital Amplification Technology: Utilizes Class D technology for efficient power usage. This results in less heat generation and extended operational lifespan of the device.
- Low Total Harmonic Distortion (THD): Features an ultra-low THD of less than 0.1%. This ensures high-fidelity sound reproduction with minimal distortion in audio playback.
- Wide Voltage Range: Operates on a power supply ranging from 12V to 24V. This versatility allows integration with various systems and battery configurations.
- Compact and Lightweight Design: The amplifier board is small and easy to mount in different enclosures. Its design is ideal for DIY audio projects and space-constrained applications.
Specification
| Specification | Details |
|---|---|
| Part Number | TXS0108E |
| Channels | 8 Bi-directional Channels |
| Direction Control | Automatic Direction Sensing for Each Channel |
| Voltage Range (VCCA) | 1.2V to 3.6V |
| Voltage Range (VCCB) | 1.65V to 5.5V |
| Max Data Rate | Up to 60 Mbps for Push-Pull Signals |
| Interface Type | Full-Duplex Logic Level Translation |
| Protection | Integrated ESD Protection (up to ±15kV HBM) |
| Propagation Delay | 5.5 ns (typical) |
| Low Power Consumption | Yes, with low quiescent current |
| Enable Pin | OE (Output Enable) Pin for Control |
| Compatibility | Compatible with 1.8V, 2.5V, 3.3V, and 5V Logic Systems |
| Operating Temperature Range | -40°C to 85°C |
| Package Types | Available in TSSOP, VQFN, and other small form-factor packages |
| Typical Applications | Level shifting in I2C, UART, GPIO, and SPI communication interfaces |
| Current Consumption | Low static current when idle |
| SKU | RW-446 |
