G-Energy 12V to 24V 5A Step-up DC DC Converter 120W Boost Voltage Regulator IP68

overview of 12V to 24V Dc power converter 120w boost voltage regulator IP68

The 12V to 24V 5A Step-Up DC-DC Converter is a important part in power management systems. It is designed to efficiently increase voltage from a 12-volt input to a stable and increased 24-volt output. This boost voltage regulator stands as best solution for many industries. And provide a reliable power for devices that demand a higher voltage.

Efficient Voltage Boost: Making Devices Work Better

This converter serves as an efficient means to boost the input voltage from 12 volts to a consistent and reliable 24-volt output. By providing a  voltage increase, it caters to a multitude of devices and equipment needed higher voltages for best usage and compatibility.

Weatherproof Design (IP68): Durability in Diverse Environments

This 12V to 24V 5A DC Converter Boost Voltage Regulator designed within an IP68-rated enclosure. The converter features a robust and weatherproof build, offers a long lasting life and protection against dust, moisture, and harsh environmental elements. Its build quality make sure a sustained performance and longevity. Which make it perfect for use in tough and harsh conditions.

General features of 12V to 24V Dc power converter:

Input Voltage Range: This converter accepts a wide input voltage range of 10-23 volts DC. This voltage boost regulator compatible with various 10-23 volt power sources commonly use in different industries and machines. Its flexibility allows it to adapt to different power systems and sources.

Output Voltage (24V DC): The main use of this converter is to provide a stable and reliable 24-volt output from the 12-volt input. This voltage increase make sure that devices need a higher voltage for best performance.

Output Current Capacity (5A): With an output current capacity of 5 amperes. This  converter can provide sufficient current to power devices or equipment that require a higher power supply. This 12v to 24v power converter allows 5A current for operation or charging of multiple devices without loosing stability.

Maximum Power Output (120W): The DC to DC converter offers a maximum power output of 120 watts. while ensuring power delivery for many kind of devices and systems that work within the 24-volt power need.

Conversion Efficiency: Working with a high conversion efficiency rate of up to 95%. This voltage boost converter minimizes energy loss during the voltage conversion process. This high efficiency help to reducing heat generation and increasing the use of input power.

Operating Temperature Range (-40°C to +85°C): This voltage booster works well in very hot or cold conditions. It stays reliable for different uses at different temperature range from -40°C to 85°C.

Protection Features: Build with best protection features, including safeguards against overvoltage, overcurrent, and short circuits. This converter ensures both its safety and the safety of using devices from damage due to electrical faults.

Datasheet

click here for datasheet of G-Energy 12V to 24V 5A Step-up DC DC Converter 120W Boost Voltage Regulator IP68 RW-929-12-24-120W
