Overview of this TCS34725 Color Sensor
Introducing Robway TCS34725 Color Sensor is a high precision module designed for accurate color detection and measurement. It features an advanced RGB color sensing system with clear, red, green, and blue filters. This allows the sensor to capture a wide range of colors and produce precise color data. The TCS34725 Colour Sensor is ideal for application such as color matching ambient light sensing and color identification.
The TCS34725 color Sensor offers easily fit with various micro controllers and development boards through its I2C communication interface. Its onboard IR filter also enhance color accuracy by reducing interference from ambient light source. The sensor compact design make it perfect for various project, from DIY electronics to industry device. And it also help to provide clear and concise output data for smooth processing and interpretation of color information.
The color sensor TCS34725 features adjustable gain and integration time settings & allow you to fine tune performance based on your specific need. Its advanced sensing technology also ensure reliable and stable color measurements. The module low power use also make it energy efficient for use in battery power project.
Features
- RGB and clear light sensing: The TCS34725 color sensor can detect red, green, blue, and clear light levels. This allows for precise best color analysis and measurements in various device.
- High sensitivity: The sensor high sensitivity enable it to detect color in a range of light condition. it also ensure accurate & igh performance even in low light environment.
- IR filter: This TCS34725 color sensor also provide an inbuilt infrared filter. And it help to reduce the impact of infrared light on color readings.
- 16-bit ADC: The sensor features a 16 bit analog to digital converter & offer a detailed data on color intensity. This high resolution also allow for best color detection and differentiation.
- I2C interface: The sensor communicates via the I2C protocol & allow for easy fit with microcontroller. It help to simplify data transmission and compatibility with popular development platform.
- Compact design: Its compact size also allows for easy use into a variety of project. It also make it perfect for less space device and portable devices.
- Programmable gain and integration time: Users can adjust the sensor’s gain and integration time for optimal performance. This customization enables adaptation to different lighting conditions and applications.
Specification
| Specification | Details |
|---|---|
| Sensor Type | Color sensor with RGB and clear light sensing |
| Spectral Range | 400 nm to 700 nm (visible light spectrum) |
| Resolution | 16-bit ADC resolution |
| Output Interface | I2C communication |
| Measurement Accuracy | ±3% typical for RGB values |
| Integration Time | Configurable (2.4 ms to 614 ms) |
| Gain Control | Configurable (1x, 4x, 16x, 60x) |
| Interrupt Capability | Programmable interrupt pins |
| Light Sensing | RGB and clear light |
| Operating Voltage | Typically 3.3V – 5V DC |
| Operating Temperature | -30°C to +70°C |
| Application | Color measurement, ambient light sensing, display adjustment, industrial color detection |
| SKU | RW-162 |
| Data Sheet |
