Overview of this tmc2208 stepper driver
Introducing the Roboway TMC2208 Stepper Driver, a cutting-edge solution for precise and quiet stepper motor control. This stepper motor driver module boasts advanced features such as flexible microPlyer interpolation unit, allowing for up to 256 microstep/step resolution, ensuring smooth and accurate movements in 3D printing and other applications. With UART functionality directly integrated, wiring complexity is significantly reduced, streamlining setup and operation.
Designed to support a voltage range of 3.3-5V, the TMC2208 stepper driver offers versatility and compatibility with various systems. Its maximum current of 1.2A per phase (continuous, with cooling) and 2A peak per phase ensures efficient motor operation even under demanding conditions. Equipped with StealthChop and SpreadCycl technologies, this driver delivers quieter operation and smoother movements, enhancing overall performance and user experience.
With built-in security features for high temperatures, high currents, low voltage, and short circuits, the TMC2208 stepper driver prioritizes safety and reliability. Additionally, it comes with a heatsink for improved cooling efficiency, further optimizing its performance and longevity. Upgrade your stepper motor control system with the Roboway TMC2208 stepper driver, offering precision, versatility, and advanced features for various applications.
Features
- UART Integration: The TMC2208 V1.2 version features direct UART functionality, simplifying wiring requirements for users.
- High Microstepping Resolution: With up to 256 microsteps per step, it ensures smooth and precise motion control, even in limited pulse rate systems.
- Compatibility with 3D Printers: Designed to be compatible with existing 3D printer electronics, reducing the need for expensive redesigns.
- Versatile Voltage Range: Operates with voltages ranging from 3.3V to 5V, accommodating various system configurations.
- Advanced Motor Control Technologies: Incorporates StealthChop and SpreadCycle technologies for quieter operation and smoother movements.
- Built-in Safety Features: Offers protection against high temperatures, high currents, low voltage, and short circuits, ensuring reliable operation in diverse conditions.
Specification
| Specification | Value |
|---|---|
| Voltage Range | 3.3-5V |
| Maximum Current | 1.2A per phase (continuous, with cooling), 2A peak per phase |
| Supported Signals | Works with 3.3V and 5V signals |
| Microstepping | Up to 1/256-step |
| Configuration | CFG pins or UART |
| Technology | StealthChop, SpreadCycl |
| Safety Features | Built-in for high temperatures, high currents, low voltage, and short circuit |
| Heatsink | Included for better cooling |
| Length (mm) | 21 |
| Width (mm) | 15 |
| Height (mm) | 13 |
| Weight (g) | 6 |
| SKU | RW-1045 |
