Description

Overview of this Hi-link URB4805YMD-10WR3 Isoalated dc converter

Introducing the Hi-link URB4805YMD-10WR3 isolated DC converter, a trusted solution for smooth voltage conversion. This power module easily transforms 48V input voltage to a stable 5V output & also deliver 10W of power with a current capacity of 2000mA. Ideal for various industry and commercial applications, the Hi-link URB4805YMD-10WR3 isolated DC converter ensures safe and stable power delivery in diverse environments.

The Hi-link URB4805YMD-10WR3 isolated power module boasts advanced feature and performance. With its isolated design, it also ensure better safety and protection for connected devices. It also built with with a 91% transfer input, it offers high efficiency & reduce energy waste and operating cost.

Experience superior efficiency and reliability with the Hi-link 48V to 5V 10W 2000mA isolated DC converter. Its compact design and robust construction also make it perfect for less space device. Trust Hi-link for exceptional quality and performance, with the URB4805YMD-10WR3 power module leading the way in power conversion solutions.

Features

Isolated Design: The Hi-link URB4805YMD-10WR3 ensures device safety with complete electric isolation. Its design also protect connected devices from potential electrical hazards & ensure smooth operation.
Efficient Voltage Conversion: Easily converting 48V to 5V, the URB4805YMD-10WR3 delivers 10W of power. Its smooth conversion capabilities also ensure optimal performance in diverse device.
High Current Capacity: With a robust 2000mA current capacity, this converter supports power-hungry devices. Users can rely on its ability to deliver sufficient power for different applications.
91% Transfer Input: This feature ensures high efficiency, reducing energy waste and operating costs. The URB4805YMD-10WR3 maximizes power usage, contributing to cost savings in the long run.
Compact and Robust Construction: Despite its small size, the URB4805YMD-10WR3 boasts a sturdy build. Its robust construction ensures durability, suitable for various installations.

Specification

Specification	Value
Input Voltage	48V
Output Voltage	5V
Output Power	10W
Output Current	2000mA
Efficiency	91%
Isolation	Electrical
Input-Output Isolation Voltage	1500VDC
Operating Temperature	-40°C to +85°C
Storage Temperature	-55°C to +125°C
Cooling Method	Free Air Convection
Dimensions (L x W x H)	25x25x12
Weight	35g
Certifications	CE, RoHS
SKU	RW-DC059

Main use of this Hi-link 48V to 5V 10W 2000mA Isolated dc converter

Industry Applications: Ensure stable 5V power supply for sensitive equipment in industry environments. The Hi-link URB4805YMD-10WR3 also provide a smooth operation of machine and control system.
Telecommunications Equipment: Provide precise power delivery to low voltage device in telecom gear. The URB4805YMD-10WR3 converter also support best performance of communication devices.
Vehicle Electronics: Enhance efficiency by converting 48V to 5V for Vehicle systems. This converter also ensures stable power supply for various vehicle electronics.
IoT Devices and Sensors: It is also use to support IoT devices and sensors with stable 5V input. The URB4805YMD-10WR3 enables smooth operation of smart devices in diverse applications.
Control Systems and Automation: Enable smooth operation of control systems and automation equipment with stable 5V power. The URB4805YMD-10WR3 converter also ensure smooth and reliable power supply for industry automation.

Environment Condition

Project name	Qualification	Unit	Notes
Working enviroment temperature of Hlk-URB4805YMD-10WR3 48V to 5V DC DC power supply module converter	-40—+85	℃
Storage temperture	-40—+80 ℃	℃
Relative humidity	5—95	%
Heat dissipation mode	natural cooling
Atmospheric pressure	80—106 Kpa	Kpa
Vibrate	Vibration coefficient 10~500Hz,2G10min./1cycle, 60min.each along X,Y,Z axes		Meet the requirements of secondary road transportation

Input Characteristics of Hlk-URB4805YMD-10WR3 48V to 5V DC DC power supply module converter

Project name	Working conditions	Unit	Notes
Related input voltage	48	Vdc
Input voltage range	18-75	Vdc
Maximum input current	≤0.4	A
Reflection ripple current	30	mA	DC12V rated input voltage series
Impulse voltage	≤100	Vdc
Starting voltage	18	Vdc
Input undervoltage protection	15	Vdc
Start-up delay	1	ms	Rated input voltage and constant resistance load
Input filter type		PI version
Hot plugged		Non-support

Output Characteristics(5V/2000mA) of Hlk-URB4805YMD-10WR3 48V to 5V DC DC power supply module converter

Project name	Technical requirement	Unit	Notes
No load rated output voltage	5V±2%	Vdc
Short-time maximum output current	≥2200	mA
Rated output current	2000	mA
Voltage regulation	±0.5	%
Load regulation	±1	%
Transfer efficiency	Vin=48Vdc, output full load 91	%
Output ripple and noise (mVp-p)	≤100 Pure resistance load, 20MHz bandwidth, peak to peak value	mV
Output over-current protection	the maximum load 110-200%	Vdc
Insulation voltage	Input- output, test in 1 minute, leakage current less than 1mA/1500V	–
Insulation resisitance	Input- output, insulation volaltge 500VDC/1000MΩ	MΩ
Isolation capacitance	Input- output, 100KHz/0.1V 1000pF	–

Typical Application Circuit

Relevant Power Module

Hi-link Power Module	Input & output	Current & power	Buy Link
Hi-link URA4812YMD-10WR3 isolated dc converter	48V to 12V	10W 833mA	Buy now
Hi-link URB4805YMD-10WR3 Isolated dc converter	48V to 12V	10W 833mA	Buy now
Hi-link B0515S-2WR3 isolated dc converter	5V to 15V	2W 133mA	Buy now
Hi-link B0524S-2WR3 Isolated dc converter	5V to 24V	2W 83mA	Buy now
Hi-link B2412S-2WR3 isolated dc converter	24V to 12V	2W 166mA	Buy now
Hi-link URB2405S-3WR3 isolated dc converter	24V to 5V	3W 666mA	Buy now
Hi-link URB2405YMD-6WR3 isolated dc converter	24V to 5V	6W 1.2A	Buy now
Hi-link URB4805LMD-40WR3 isolated dc converter	48V to 5V	40W 8A	Buy now
Hi-link VRB1212YMD-5WR3 isolated dc converter	12V to 12V	5W 416mA	Buy now

-54%

roboway Hi-link URB4805YMD-10WR3 48V to 5V 10W 2000mA DC to DC 91% Transfer Input Isolated Power Supply Module Converter

Hi-link URB4805YMD-10WR3 48V to 5V 10W 2000mA DC to DC 91% Transfer Input Isolated Power Supply Module Converter

Click to enlarge

Back to products

Hi-link URB4805YMD-10WR3 48V to 5V 10W 2000mA DC to DC 91% Transfer Input Isolated Power Supply Module Converter

SKU: RW-DC059

Original price was: ₹1,499.00.Current price is: ₹684.00. ( Excluding 18% GST )

Input Voltage	48V
Output Voltage	5V
Output Power	10W
Output Current	2000mA
Efficiency	91%

In stock

Add to wishlist

For bulk and B2B enquiries kindly mail us at info@roboway.in

Tags: hilink-URB4805YMD, hilink-URB4805YMD-10WR3, hlk-URB4805YMD, hlk-URB4805YMD-10WR3, URB4805YMD, URB4805YMD-10WR3, URB4805YMD-10WR3 48V to 5V 10W 2000mA DC to DC 91% transfer input power supply module converter
