Description
Overview of this TB6612FNG Dual Motor Driver Module 1A for Arduino
Introducing Roboway TB6612FNG Dual Motor Driver Module 1A for Arduino at best price. A versatile motor control solution design for arduino projects and developers. This module allows you to control up to two DC motor with a constant current of 1.2A, with a peak current capability of 3.2A.
This tb6612fng dual motor driver also feature four function mode CW, CCW, short-brake, and stop. This motor driver module offers flexible control option for various motor use. Each motor output (A and B) can easily control with PWM input signal. And enable precise speed adjustment up to 100kHz.
With a wide operating voltage range of 2.7-5.5VDC for logic supply and a maximum motor supply voltage of 15VDC. This module also provide reliable and efficient motor control for your Arduino project. Its compact size, LED indicator, and built-in thermal shutdown circuit make it perfect for robotic, automation, and DIY project.
Features
- Dual Motor Control: The TB6612FNG motor driver can easily control two DC motors with a constant current of 1.2A (3.2A peak) & provide versatile motor control option.
- Four Function Modes: It supports four motor control modes – CW (clockwise), CCW (counterclockwise), short-brake, and stop. And these function enable for precise motor control for various application.
- PWM Speed Control: Each motor speed can adjust via PWM input signal with a frequency of up to 100kHz. And allow fine tuning of motor speed.
- Standby Mode: The STBY pin can be pulled high to put the module in standby mode. And save power when the motors are not in use.
- Wide Operating Voltage: It operates with a logic supply voltage (VCC) ranging from 2.7V to 5.5VDC, and motor supply voltage (VM) up to 15VDC. And also ensure smooth function with different power source.
- Overload Protection: This TB6612FNG Dual Motor Driver Module 1A for Arduino also provide built in thermal shutdown and low voltage detection circuit. These function provide protection against overheating and voltage change & enhance the module reliability.
- Compact Design: With dimensions of 30mm x 20mm x 10mm and weighing only 22g. This module offers a compact form factor suitable for various Arduino projects.
Specification
| Specification | Details |
|---|---|
| Motor Driver Model | TB6612FNG Dual Motor Driver Module 1A |
| Operating Voltage (VDC) | Up to 15 |
| Peak Current (A) | 3.2 |
| Continuous Current (A) | 1.2 |
| No. of Channels | 1 |
| PWM Frequency | Up to 100 kHz |
| Motor Control Modes | CW, CCW, short brake, stop |
| Standby Control | Yes, to save power |
| Built-in Protections | Thermal shutdown circuit, low voltage detecting circuit |
| Logic Supply Voltage (VCC) | 2.7 – 5.5 VDC |
| Motor Supply Voltage (VM) | Up to 15 VDC |
| Output Current | 1.2A average, 3.2A peak |
| Interface | All pins broken out to 0.1 spaced pins |
| LED Indicator | Yes |
| Cooling Fan | No |
| Arduino Shield Compatible | No, but can be used with wire connections |
| Polarity Protection | No |
| Dimensions (mm) | 30 x 20 x 10 |
| Weight (g) | 22 |
| SKU | RW-909 |
