G-energy Dc 75-145V To 24V 20A 480W Dc Dc Converter IP68 Step Down Power Supply Module

SKU: RW-1413

9,499.00 ( Excluding 18% GST )

Only 4 left in stock

Purchase & earn 950 points!


Frequently bought together

G-energy Dc 90V 110V To 24V 20A 480W Dc Dc Converter IP68 Step Down Power Supply Module
roboway PCT-222 Quick Connector 4 Terminal 2 In-2 Out Lever Wire Connector
roboway PCT-221 Quick Wire Connector 2 Terminal 1 In-1 Out Lever Wire Connector
This item: G-energy Dc 75-145V To 24V 20A 480W Dc Dc Converter IP68 Step Down Power Supply Module 9,499.00 ( Excluding 18% GST ) 9,499.00 ( Excluding 18% GST )

Only 4 left in stock

PCT-222 Quick Connector 4 Terminal 2 In-2 Out Lever Wire Connector 19.00 ( Excluding 18% GST )

Out of stock

6 People watching this product now!

Overview of this 90V 110V To 24V 20A 480W Dc Dc Converter

Introducing Roboway DC 90V 110V to 24V 20A 480W DC-DC Converter  at best price in India with Roboway. This 90V 110V to 24V 20A 480W buck converter step down high input voltage to a stable 24V output with a 20A capacity. It is specially design with an IP68 waterproof housing, it ensure durability and reliable operation in harsh environment. This 90V 110V to 24V 480W step-down DC converter is ideal for industrial, automotive, and outdoor power need.

It also deliver excellent energy efficiency, this 90V 110V to 24V 20A DC converter support high demand application with less power loss. Its high quality built allow easy fit into various setup, including LED systems, machine, and solar power system. With a high power output, it guarantees reliable performance for heavy duty device.

Features

  • Wide Input Voltage Range: This 90V 110V To 24V 20A 480W dc dc converter operate with a dc input of 75-145V & ensure compatibility with diverse system.
  • High Output Power: It can deliver a stable 24V output at 20A & provide up to 480W of power. Perfect for high performance device need stable and efficient energy supply.
  • IP68 Waterproof Design: This 110V to 24v dc dc converter built with an ip68 rating & offer full protection against water, dust, and harsh condition.
  • Efficient Energy Conversion: It can achieve high efficiency & reduce power loss and reducing heat for reliable performance. Ensures optimal function during continuous and heavy duty operation.
  • Compact and Robust Build: It also feature a sturdy yet compact design for easy installation in tight space.

Datasheet of GEMSD1102420 Dc 90V 110V To 24V 20A 480W Dc Dc Converter

Specification

Specification Details
Rated Voltage 110V/120V
Input Voltage Range 75-145V
Efficiency Up to 91%
Output Voltage 24V
Maximum Output Current 20A
Maximum Output Power 480W
Voltage Regulation ±1%
Load Regulation 2%
No-Load Loss 70mA
Ripple Noise 120mV (Full Load)
Operating Temperature -40°C to +80°C
Storage Temperature -40°C to +100°C
Operating Humidity 10% to 90% RH
Short Circuit Protection Yes
Overcurrent Protection Yes
Overvoltage Protection Yes
Overtemperature Protection Yes
Waterproof Rating IP68
Model RW-358-75-145-24-480W
SKU RW-358
